GottFA80_Plus — All-in-One CPU Board (replaces MPU + Driver + power supply) for Gottlieb System 80/80A/80B pinball

€349,00 EUR

Sale Sold out

Taxes included.

Low stock: 1 left

Please check the model before ordering

Every board is configured for one specific game. Select the model in the list that matches your machine exactly — a similar model will not work. If in doubt, get in touch before ordering: we will check compatibility with your machine free of charge.

GottFA80_Plus V2 — Light version (no sound)

All-in-one replacement CPU board for Gottlieb System 80 and 80A pinball machines (partial System 80B support). The GottFA80_Plus replaces the MPU + Driver + power supply in a single Plug & Play board, with true Freeplay and the original Gottlieb ROMs interpreted directly in the FPGA — no software emulation, no battery, scores saved.

Key features

Plug & Play — ready to use, no A1-J4 / A3-J1 cable needed.
Replaces MPU + Driver + power supply (System 80 & 80A).
Compatibility: System 80, 80A, and partial System 80B.
True Freeplay — the game boots ready to play, no credits needed.
Reliable — no freezes, no battery, scores saved.
Original ROMs interpreted in the FPGA — faithful hardware interpretation, gameplay identical to the original board.
Respects original functions: dipswitches, Slam control, ROMs up to the late 80B.

Included free · Smart FA module

FA·CONTROL: test your pinball from your phone

This board comes with FA·CONTROL, our Wi-Fi service tool. Open a web browser on your phone, tablet or laptop and test your machine part by part. No app to install, no extra hardware.

The FA·CONTROL home screen in a web browser, with buttons for lamps, coils, switches, game RAM, sound, displays, Wi-Fi, names, FPGA and self-test.

The real FA·CONTROL home screen: every test is one click away.

What you can do from your browser

Lamps
Switch any lamp on or off to spot a dead bulb or a faulty lamp circuit.

Coils
Fire any coil on its own to check the coil and its drive circuit.

Switches
Watch every switch react live as you press it on the playfield.

Displays
Drive the score displays to check every digit and segment.

Sounds
Play the game's sounds one by one to check the sound side.

Game memory
Read the game's memory live while it plays, for advanced troubleshooting.

Names
Load a names file for your game, so tests show real names instead of numbers.

Wi-Fi & updates
Put the board on your home Wi-Fi and install new firmware versions.

Self-test
Run the board's self-test in one click.

A laptop on a Gottlieb playfield showing the FA·CONTROL switch grid while a hand presses a switch on the playfield.

Switch test on a Gottlieb: press a switch on the playfield and watch it light up on screen.

How it works

Power on the machine.
Connect your phone or laptop to the board over Wi-Fi. Once the board is on your home Wi-Fi, you'll find it at fa-control.local.
Open FA·CONTROL and pick a test. FA·CONTROL takes control of the board while you test, so nothing fires on its own. Release control and the game plays again.

Stand at the playfield with your phone in hand and test one part at a time, instead of going back and forth to the test buttons in the coin door.

A GottFA80_Plus board with the Smart FA module plugged in on its right side.

The Smart FA module (right), plugged on a GottFA80_Plus. It runs FA·CONTROL.

FA·CONTROL is our version of the LISY pinball service tool. It runs on the Smart FA, the FPGA module we design, make and assemble ourselves, and on its ESP32 Wi-Fi chip, and it speaks the protocol of the open LISY project (lisy.dev). Available on the GottFA80_Plus (Light and Full) and the WillFA7: free, included with the board, and improved through free updates.

Learn more

Pinball compatibility

System 80: Panthera, Spiderman, Circus, Counterforce, Star Race, James Bond, Time Line, Force II, Pink Panther, Mars, God of War, Volcano, Haunted House, Eclipse, Black Hole (Export only).

System 80A: Devil's Dare, Rocky, Spirit, Punk, Striker, Krull, Q*Bert's Quest, Super Orbit, Royal Flush Deluxe, Goin' Nuts, Amazon Hunt, Rack 'Em Up, Ready...Aim...Fire!, Jacks To Open, Touchdown, Alien Star, The Games, El Dorado City of Gold, Ice Fever.

System 80B — full support: Bounty Hunter, Chicago Cubs Triple Play, Tag Team, Raven, Rock, Rock Encore, Hollywood Heat, Genesis, Gold Wings, Monte Carlo, Amazon Hunt II, Spring Break, Arena, Victory.

System 80B — partial (slightly raise the GI to insert the board; the display cable may need an extension): Diamond Lady, TX Sector, Robo War, Excalibur, Bad Girls, Big House, Hot Shots, Bone Busters Inc.

System 80B note: keep the original power supply on 80B games.
